SimplyCam / SimplyLaser

SimplyCam is a simple Cad/Cam system that creates 2D toolpaths. The geometric part can be created internally, with the available tools or imported from external file.
The main features of SimplyCam are:

  • Opening, creating, editing and saving geometry in industry standard DXF format.
  • Opening Svg file.
  • Vectorization with median line or outer edges mode of the raster images (Bmp and Jpeg) with recognition of arcs and circles.
  • Creating geometry with the Line, Rectangle, Arc, Circle, Ellipse, Polylinea and Spline functions.
  • Changing the geometry with the Fillet, Trim, Break, Merge, Split, Extend and Explode block functions.
  • Transform entity with Scale, Rotate, Mirror, Offset and Translate commands.
  • Conversion of any TrueType font into vectors.
  • Generation programs for CNC machines such as milling machines, Router, Water Jet, Laser, Plasma and Lathe machines.
  • Operations Manager to control all elements of the toolpath
  • Included great number of open post-processor such as:
  • AutoGrav, Emc2, Fadal, Fanuc, Haas, Heidehain, Iso, KCam, Mach2/3, MaxNc, PlasmaCam, ProtoTrak, Selca, Siemens, ShopBot, Tecno-Isel, TurboCnc, ....
  • Opening, editing and simulation of the programs in G-Code format.
  • Opening/Saving geometry and toolpath with modification and recalculation.
  • Interface with toolbars and panels draggable.

Now the Simply products are divided into modules and using the same interface

  • SimplyCam for Milling toolpaths
  • SimplyLaser for Laser, Plasma and WaterJet toolpaths
  • SimplyLathe for Turning toolpaths. Note: No further development.
  • SimplyLathe module will no longer be updated and supported.
  • The buy of the license allows the use of all modules
Download Order Now
System Requirements

Microsoft Windows 98, ME, 2000, XP, Vista, Windows 7/8/10
Pentium 3/4 or AMD CPU - 300 MHz or more
True color Video Card - 800 x 600
256 Mb RAM
5 Mb free disk space

Info

Version: 3.66 Trial
Released: January 24, 2020
File Size: 1.7MB
Free Trial Limitation:
Drawing cannot be saved in Dxf
Only up to 100 lines of G-Code are generated
